Dynacord L2800FD DSP 2 x 1400 w power amplifier for live performance applications

Dynacord L2800FD DSP 2 x 1400 w power amplifier for live performance applications

Professional DSP amplifier for live and mobile application
Fully integrated professional speaker processing with FIR drive technology
Market-leading acoustic performance and rock solid reliability
Intuitive, simplified set-up, control and operation in SONICUE sound system software with firmware 2.0

Dynacord L Series are professional dual channel audio amplifiers for live and mobile applications. Integrated digital signal procesing provides access to professional speaker processing with FIR Drive technology. L Series amplifiers utilize Class A/B resp. Class H topologies, which provide market leading acoustic performance and reliability. The connectivity is optimized for the needs of mobile applications. A front panel LC display allows local control and supervision of the amplifier. An intuitive system control software allows fast system setup, flexible system control and comprehensive

Order now, your order will Dispatch in 24 hours!

116000 185000.00Save 37%

quantity

Buy Now Add to Cart

Buy Now

Add to Cart

Availability: 5 in stock Free Delivery available on this product.

Limited Period Offer : Get Flat 10% off! use Coupon Code: "SAVE10" at checkout.

Buy Premium Warranty- With Free Pickup and Return T&C*

3 Year Standard Warranty
Lifetime Tech Support
4% Cashback
15-Day Return
Dedicated Product Specialists

Get Amazing Discounts for more Enquiries please Contact us

+91-97756-80039 or Whatsapp

Description

Load Impedance	2 Ω	2.7 Ω	4 Ω	8 Ω
Maximum Output Power, Single Channel	2300 W	2000 W	1400 W	700 W
Maximum Output Power, Dual Channel	2200 W	1800 W	1300 W	650 W
Maximum Output Power, Bridged	-	-	4400 W	2600 W
Specifications

Maximum RMS Voltage Swing THD = 1%, 1 kHz	78.8 V
Voltage Gain Ref.1 kHz	32.0 dB
THD at 900 W/4 Ω MBW = 80 kHz, 1kHz	< 0.05%
IMD-SMPTE, 60 Hz, 7 kHz	< 0.1%
DIM30, 3.15 kHz, 15 kHz	< 0.05%
Maximum Input Level	+21 dBu
Crosstalk ref. 1 kHz, at 100W/4 Ω	< -80 dB
Frequency Response, ref. 1 kHz	10 Hz to 21 kHz (±1 dB)
Input Impedance, Active Balanced	20 k Ω
Signal to Noise Ratio Amplifier, A-weighted, ref to Max. Output Power@ 8 Ω	>107 dB
Output Noise, A-weighted	< -68 dBu
Output Stage Topology	Class H
Power Requirements	240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz(factory configured)
Power Consumption ? Maximum Output Power @ 4 Ω	700 W
Mains Fuse	240 V/230 V: T15AH; 120 V/100 V: T25AH
Protection	Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay
Cooling	Front-to-rear, 3-stage-fans
Ambient Temperature Limits	+5°C to +40°C (40°F to +105°F)
Safety Class	I
Color	Black
Dimensions (W x H x D), mm	483 x 88 x 462.4
Weight	16.2 kg (35.7 lb)
Signal Processing	FIR filters, audio limiters, output and array delay, 10-band user PEQ, 5-band array PEQ** per channel, load impedance
Remote Control	SONICUE sound system software **
Accessories	RMK15 (rear rack mount kit)
